3 Series E36 325i (M50) CONVER
63 17 000
Removing and installing/replacing left or right
foglight insert
Unclip headlight by inserting a screwdriver through upper
aperture. Pull off connector. Disconnect steel-wire clamp and pull
out light bulb.
Caution!
Do not take hold of glass part of bulb with bare fingers. Only
take hold of bulb on base or with a clean cloth or packaging of
light bulb.
If necessary, adjust foglight,
refer to 63 10 014
Roadster
Unclip and remove finisher
Unfasten screws, pry out headlight insert and remove connector.
RA Removing and installing/replacing left or right foglight insert
