To prevent damage to the plug connector on the airbag module,
the following assembly sequence must be observed:
-
Caution!
Always replace micro-encapsulated screws!
Screw down side airbag module
Tightening torque,
refer to Technical Data 72 12 1AZ
-
Attach adapter lead to side airbag module,
-
Mount retaining clip, replace damaged clip if necessary.
RA Removing and installing/replacing airbag module on left or right front door
