3 Series E36 325is (M50) COUPE
Fold up wiper arms up to end position and detach in direction of
arrow from drive shaft.
Installation:
Only install in following sequence:
1.
Run wiper motor into rest position.
2.
Switch off wipers.
3.
Fit wiper arms.
4.
Close engine hood.
5.
Fit wiper blades.
6.
Adjust wiper arms.
Adjusting dimensions of wiper arms:
Reference points are the mountings of the wiper blades on the
wiper arms to the sealing lip of the cowl panel.
4-door models:
A = 50 mm
B = 50 mm
2-door:
A = 43 mm
B = 53 mm
RA Removing and installing/replacing both windshield wiper arms
