3 Series E36 325is (M50) COUPE
LCD test (LCD):
Four different test patterns are switched on in series for all light emitting diodes (LEDs) during the LCD test:
1.
All LEDs switched on
2.
Chessboard pattern
3.
Chessboard pattern inverted for second test
4.
All LEDs switched off
The test can be stopped at any time by pressing key "0", but also returns to the main menu after display of all four test
patterns.
Road Speed Dependent Loudness Control (GAL):
With help of this test one of the three road speed dependent loudness tables is activated, through which one each road
speed dependent loudness offset can be determined and reported to the radio.
The instantaneously activated table can be read in the B-display.
The table number is stored in EEPROM.
Return to the main menu is accomplished by pressing the key below "END".
RA Test Mode for BMW Car Radio (Bavaria C Professional RDS)
