3 Series E36 328i (M52) COUPE
Fit bearing cover.
Note:
The bearing covers are clearly marked and can be read from
the exhaust end:
A1 ... A7 for the exhaust end
E1 ... E7 for the intake end
Fit special tool 11 3 260 to cylinder head and screw into spark
plug threads of cylinders 1 and 4.
Tightening Torque,
refer to Technical Data 12 12 1AZ
Turn the eccentric shaft to pre-tension the bearing caps.
Tighten down bearing cover.
Tightening Torque,
refer to Technical Data 11 31 1AZ
Remove special tool 11 3 260.
Caution!
Do not damage the cylinder head.
Machine open-end wrench accordingly if necessary.
Align camshafts with open-end wrench.
RA Replacing camshaft (M52/S52)
