3 Series E36 328i (M52) COUPE
Installation:
Backrest lock must engage correctly.
Move cable laterally back and forth in the holders so that the cable
"settles" (free of play!).
Caution!
Do not pull on cable.
Use new retainer.
Unclip ball socket.
Push cable forward and detach it.
Installation:
Backrest unlocking cable (1) must be routed as shown.
RA Removing and installing/replacing backrest shell on left or right front seat
