3 Series E36 M3 (S52) COUPE
Installation:
Lockpin (1) must engage in opening (2) of contact ring.
Tightening Torque,
refer to Technical Data 32 33 1AZ.
Adjust contact ring if necessary:
Press down spring (1). Turn contact clockwise or
counterclockwise as far as stop. Turn back about 3 turns until
arrows for centre position are aligned.
Release spring (1).
Installation:
Coat slip ring with grease, refer to BMW Service Operating
Fluids.
RA Removing and installing steering wheel (with airbag)
