3 Series E36 M3 (S52) SAL
Unfasten screws and remove guide tube.
Tightening torque, 23 11 2AZ.
Note:
Two covered removal holes (1) are located on the end face of
the radial sealing ring.
Screw special tool 23 0 490 into one of two removal holes.
Pull radial sealing ring out of transmission housing with impact
weight.
Fit special tool 23 2 380 onto transmission input shaft.
Coat sealing lips of new radial seal (1) with transmission oil and
slide firmly home on transmission case.
Remove special tool 23 2 380 from drive shaft.
RA Replacing drive shaft radial seal (S5D 260Z/ 310Z/ S5D 320Z)
