3 Series E36 M3 (S52) SAL
33 2 200
Fixture
Minimum set: Mechanical tools
In conjunction with:
33 4 200, 33 5 070
Note:
For removing and installing output shaft in
drive flange as well as for removing front
wheel bearing unit.
Series:
E30, E31, E32, E34, E36, E36/2, E36/3,
E36/5, E36/7, E36/C, E36tou, E38, E38/3,
E39, E39PL, E39tou, E46, E52, E53, E60,
E61, E63, E64, E65, E66, E67, E70, E71,
E81, E82, E83, E85, E86, E87, E88, E90,
E91, E92, E93, RR1, RR2
Order number:
33 2 200
Fixture
Consisting of:
1 = 33 2 201
Basic body
2 = 33 2 202
Counterholder
In conjunction with: 33 5 070
3 = 33 2 203
Spindle M20x1.5 / length 150 mm
Note: For pressing out. Model series: E30,
E31, E32, E36, E38, E39, E46, E53, E65,
E66, E67, E83, E85
4 = 33 2 204
Spindle M20x1.5 / length 180 mm
Note: For drawing in. Model series: E30
5 = 33 2 205
Spindle M20x1.5 / length 190 mm
Note: For drawing in. Connection: M27x1.5
Model series: E31, E52, E53, E60, E61, E65,
E66, E67, E83
6 = 33 2 206
Spindle M20x1.5 / length 190 mm
Note: For drawing in. Connection: M24x1.5
Model series: E36, E46
7 = 33 2 207
Threaded piece
8 = 33 2 208
Nut with thrust bearing
Note: Model series: E30, E31, E32, E36,
E38, E39, E46, E52, E53, E60, E61, E65,
E66, E67, E83, E85, RR1
SWZ Fixture
BMW AG - TIS
11.02.2013 10:37
Issue status (12/2007) Valid only until next DVD is issued
