3 Series E36 M coupe (S52) COUPE
Fit special tool 11 2 385 to crankshaft.
Align groove of special tool 11 2 385 to featherkey of
crankshaft.
Note:
Special tool 11 2 385 centers special tool 11 2 380 .
Screw in special tool 11 2 380 until it has made firm contact with
radial seal.
Remove radial seal by tightening screw on special tool.
Installation:
Coat sealing lips of new radial sealing ring with oil.
Using special tool 11 3 280 and centering screw, install new
radial seal flush with timing case cover.
RA Replacing radial seal in lower timing case cover
