3 Series E36 Z3 coupe (M54) COUPE
If necessary, remove control piston.
Press sleeve downwards with suitable drift.
Caution!
The sleeve for the control plunger is under spring pressure.
Remove circlip.
Installation:
1.
Control plunger
2.
Spring
3.
Sleeve
4.
O-ring (replace)
5.
Circlip
RA Removing and installing/replacing oil pump (M52TU / M54 / M56)
