3 Series E36 Z3 coupe (M54) COUPE
25 16 202
Replacing cable for gear selector lever
Special tools required:
•
24 5 210
Slacken nut (1).
Caution!
To prevent deformation of cable, grip clamping screw with
special tool 24 5 210 .
Note:
Special tool 24 5 210 can only be connected in P position.
Remove cable from counter support.
Pull out cable.
Installation:
Adjust shifting.
Remove fillister head screw (internal hexagon 3 mm).
Tightening torque, 25 16 2AZ.
Pull off handle with pull rod.
RA Replacing cable for gear selector lever
BMW AG - TIS
11.02.2013 05:16
Issue status (12/2007) Valid only until next DVD is issued
