3 Series E46 316Ci (M43TU) COUPE
11 25 Pistons with Rings and Pins M43TU B 19
1st groove
End clearance a)
mm
0.2 ... 1.0
End float a)
mm
0.02 ... 0.20
2nd groove
End clearance a)
mm
0.2 ... 1.0
End float a)
mm
0.02 ... 0.10
3. Groove (U-Flexring)
x
End clearance
mm
not measurable
End float
mm
not measurable
a) Upper value is wear limit
