3 Series E46 316ti (N42) COMP

Page 2
background image

Remove heat shield (1).

Remove heat shield (1).

Unfasten screws.

Cut through cable tie (1).

Remove cover plate (2).

RA  Removing and installing automatic transmission (A5S 360/390R, N42/N46)

BMW AG - TIS

25.01.2013  16:03

Issue status (12/2007) Valid only until next DVD is issued

Copyright

Page  - 2 -
