3 Series E46 316ti (N42) COMP
11 24 Connecting Rods and Bearings N42
∅
Large connecting rod eye (without bearing)
mm
53.600
+0.016
Conrod bushing: Inside diameter
mm
20
+0.013
+0.004
Permissible total deviation of
connecting rods in one engine
(without bearing shells)
g
±
5
