3 Series E46 318d (M47) TOUR
11 12 000
Removing and installing/sealing cylinder head
cover (M47)
Caution!
When working on the oil, coolant or fuel circuit, you must
protect the alternator against contamination.
Cover alternator with suitable materials.
Failure to comply with this procedure may result in an alternator
malfunction.
E46 only:
Release expansion rivets (1).
Slide covers approx. 2 cm towards rear and lift out.
E46 and E39:
Remove air cleaner element.
Remove intake air manifold.
Remove injection lines.
Remove injection nozzles.
Release screws and remove intake fitting.
