3 Series E46 318d (M47) TOUR
13 62 531
Replacing coolant temperature sensor (M47)
Switch off ignition.
Caution!
When working on the oil, coolant or fuel circuit, you must
protect the alternator against contamination.
Cover alternator with suitable materials.
Failure to comply with this procedure may result in an alternator
malfunction.
Note:
Follow instructions for disconnecting and connecting battery,
refer to General Information MG 12.
Disconnect and cover battery negative lead.
Remove intake air manifold,
refer to 11 61 050.
Disconnect plug connection for needle motion sensor (1) at cable
duct.
If necessary, pull plug from glow plug, cylinder 4.
RA Replacing coolant temperature sensor (M47)
