3 Series E46 318i (N42) SAL
11 00 Engine in general N42 B18
Cylinder
4
Bore
mm
84
Stroke
mm
81
Effective displacement
cm
3
1796
Compression ratio
:1
10.25
Max. permissible engine speed
rpm
6500
±
50
Permissible constant speed
rpm
6300
Compression pressure:
Minimum and maximum values depending on position of
Valvetronic.
bar
9 ... 18
Compression pressure:
Maximum devaition of all cylinders to each other.
bar
2
TD Engine in general N42 / B18
BMW AG - TIS
12.02.2013 08:01
Issue status (12/2007) Valid only until next DVD is issued
