3 Series E46 318ti (N42) COMP
33 00 Rear axle - ride height E46 COMP from 03/03
Ride level in normal position (attach tape measure to rim
flange at bottom middle and measure to lower edge of
wheel arch)
Deviation from nominal value for all wheels together
max. mm
10
Series
15" rim
mm
±
10
542
16" rim
mm
±
10
555
17" rim
mm
±
10
568
18" rim
mm
±
10
581
Low-slung sports suspension
15" rim
mm
±
10
526
16" rim
mm
±
10
539
17" rim
mm
±
10
554
18" rim
mm
±
10
567
