3 Series E46 318ti (N46) COMP
11 12 Cylinder Head with Cover N46
Cylinder head height: Original dimension
mm
143.30
±
0.07
Machining limit
mm
143.00
±
0.07
Valve guides are not available as replacement parts.
Inside diameter of installed valve guide
Standard
mm
6.0 H7
Tilt clearance, maximum
(wear between valve and valve guide)
mm
0.5
Bearing of camshaft
Guide bearing (width)
mm
19.935 ... 19.900
TD Cylinder Head with Cover N46
