3 Series E46 320i (M54) TOUR
13 62 511
Replacing intake air temperature sensor
(M52TU, M54)
Turn off ignition.
Remove cover from fuel injectors.
Disconnect plug connection (1) for temperature sensor.
Press catch and withdraw temperature sensor (1) from intake air
manifold.
Installation:
Check sealing ring on temperature sensor for damage, replace if
necessary.
Coat sealing ring with antiseize agent.
RA Replacing intake air temperature sensor (M52TU, M54)
