3 Series E46 325i (M54) SAL
23 42 515
Replacing selection angle brake solenoid
valve GS5S31BZ (SMG)
Note:
After completing work:
Proceed according to test program.
refer to "Service Functions" in DIS Tester.
Check fluid level in hydraulic system.
Important!
Depressurize hydraulic system.
Proceed according to "Service Functions" in DIS Tester.
Remove heat shield from valve block.
Release screw (1).
Release screws (3) on protecting plate.
Tightening torque, 23 41 8AZ .
Release screws (4) on protecting plate.
Tightening torque, 23 41 7AZ .
Disconnect plug connection (1).
RA Replacing selection angle brake solenoid valve GS5S31BZ (SMG)
BMW AG - TIS
14.02.2013 01:33
Issue status (12/2007) Valid only until next DVD is issued
