3 Series E46 325i (M54) SAL
Release retaining screws (1) and (2) for hydraulic lines.
Tightening torque, 23 41 12AZ .
Installation:
Replace hydraulic lines.
Release retaining screws (3) and (4) for hydraulic lines.
Tightening torque, 23 41 12AZ.
Installation:
Replace hydraulic lines.
Release screw.
Tightening torque, 23 41 8AZ .
Release retaining screws (5) for hydraulic line.
Tightening torque, 23 41 12AZ.
Release clamp (6).
Detach hose (7).
Installation:
Replace clamp (6).
Pay attention to position of cable clamp.
Release screws.
Tightening torque, 23 41 8AZ .
Remove valve block (8).
Installation:
Pay attention to position of cable clamps.
RA Replacing valve block GS5S31BZ (SMG)
