3 Series E46 325i (M54) SAL
52 13 ...
Removing and installing/replacing guide for
front left or right head restraint
Necessary preliminary tasks:
•
Remove rear panel on front seat backrest
•
Remove head restraint
Guide for head restraint with pushbutton:
Release catches (1) and (2) and slide guide (3) upwards.
Pull guide (1) out of backrest (2).
Installation:
Catches (1) and (2) on guide (3) must not be damaged.
Check that pushbutton (4) works properly.
After installing guide (3), make sure it is properly seated.
