3 Series E46 330d (M57) SAL
12 31 020
Removing and installing/replacing alternator
(M57)
Read fault memory of DDE control unit.
Switch off ignition.
Remove front underbody protection.
Observe instructions for disconnecting and connecting battery.
Disconnect battery negative lead from battery and lay to one side.
Caution!
When working on the oil, coolant or fuel circuit, protect the
alternator against contamination.
Cover alternator with suitable materials.
Failure to comply with this procedure may result in an
alternator malfunction.
Caution!
If the charge air hoses are not fitted without grease and dry,
this will result in supercharger failure.
Fit charge air hoses without grease and dry.
RA Removing and installing/replacing alternator (M57)
BMW AG - TIS
15.02.2013 05:15
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 1 -
