3 Series E46 330d (M57) SAL
26 11 000
Removing and installing complete propeller
shaft (M57)
Remove rear underbody protection.
Remove complete exhaust system.
Remove heat shield (1).
Unfasten screws.
Installation:
Replace self-locking nuts.
The screw connection may only be tightened by means of the
nut.
Important!
The screw without washer may only be tightened by means of
the nut.
The screw with rolled-on washer which has ribbed teeth facing
the support side must be tightened by means of the screw.
Observe different tightening torques.
Tightening torque 26 11 1AZ
.
