3 Series E46 M3 CSL (S54) COUPE
M3 CSL only:
Unlock lug (1) from holder.
Feed out battery positive lead (2).
Not applicable to M3 CSL:
Detach guide tube (1) for oil dipstick from intake air manifold.
Press locks on vacuum hose (2) and detach.
Detach tank venting valve (1) from holder on intake air manifold.
Release support bracket at front and rear from intake air manifold.
RA Removing and installing intake air manifold (S54)
