Removing Rear Window Installation Guide for BMW M3 CSL Model
Caution!
Before setting new spacer buffers,
remove remnants of old spacer buffers completely (broken
rear window).
Fit two spacer buffers at a distance (200 mm) from center of
cowl panel.
Cut nozzle to size.
(A) 7 mm
(B) 12
+1
mm
Note:
To apply uniform glue bead, use cartridge pistol, operated
with compressed air or electric power (refer to BMW Parts
Service).
Note expiry date of glue!
If applicable, produce a sample bead before gluing.
Cartridge must be arranged vertically against rear window.
Caution!
Version with rear window antenna:
No glue must come into contact with the connection contacts
of the rear window heating/antenna.
RA Removing and installing rear window
BMW AG - TIS
16.02.2013 23:32
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 6 -
