3 Series E46 M3 CSL (S54) COUPE

Page 2
background image

Remove screws (1) and (2).

Lift out heater bulkhead.

RA  Removing and installing/replacing heater bulkhead

BMW AG - TIS

17.02.2013  00:11

Issue status (12/2007) Valid only until next DVD is issued

Copyright

Page  - 2 -
