3 Series E46 M3 (S54) COUPE
Remove intake air manifold.
Remove throttles.
Pull lock and detach water hoses (1 and 2).
Installation:
Refer to general instructions for work on cooling system.
Drain power steering supply tank, detach from left carrier bracket
and tie to one side.
Note:
Lines remain connected.
Remove fan clutch with fan impeller from water pump.
Remove engine oil cooler.
Remove radiator.
Remove alternator drive belt.
Remove vane pump for power steering and tie back to one side.
Note:
Lines remain connected.
RA Removing and installing engine (S54)
