3 Series E46 M3 (S54) COUPE
13 51 630
Replacing fuel pressure regulator (S54)
Turn off ignition.
Release screws (1).
Remove cover (2).
Installation:
Ensure seal (1) is in correct installation position.
Detach vacuum hose (1).
Remove snap ring (2).
Recycling:
Catch and dispose of escaping fuel.
Pull out fuel pressure regulator (3).
Installation:
Note installation position of fuel pressure regulator (3).
RA Replacing fuel pressure regulator (S54)
BMW AG - TIS
16.02.2013 13:51
Issue status (12/2007) Valid only until next DVD is issued
