3 Series E46 M3 (S54) COUPE
13 62 560
Removing and installing/replacing air-mass
flow sensor (S54)
Turn off ignition.
Unlock plug (2) and detach from air-mass flow sensor (1).
Release screws (3).
Withdraw air-mass flow sensor (1) from intake pipe.
Installation:
Check O-ring for damage, replace if necessary.
Note:
Interrogate fault memory of DME control unit.
Check stored fault messages.
Rectify faults.
Then clear fault memory.
RA Removing and installing/replacing air-mass flow sensor (S54)
