3 Series E46 M3 (S54) COUPE
13 62 531
Replacing coolant temperature sensor (S54)
Necessary preliminary tasks:
•
Read out fault memory of DME control unit.
•
Switch off ignition.
•
Remove intake air manifold.
Unlock plug (1) and detach from idle-speed control valve.
Unlock plug (2) and detach from temperature sensor (3).
Unscrew temperature sensor (3).
Tightening torque, 13 62 2AZ
.
Installation:
Check coolant level, top up coolant if necessary.
Note:
Interrogate fault memory of DME control unit.
Check stored fault messages.
Rectify faults.
Then clear fault memory.
RA Replacing coolant temperature sensor (S54)
BMW AG - TIS
16.02.2013 14:14
Issue status (12/2007) Valid only until next DVD is issued
