3 Series E46 M3 (S54) COUPE
18 20 020
Removing and installing intermediate pipe
with catalytic converter
Special tools required:
•
31 2 220
Warning!
Scalding hazard!
Only perform these tasks after exhaust system has cooled
down.
Remove underbody protection.
US version:
Front pipes are fitted in place of the ECE catalytic converter.
ECE version:
Release screws.
Unclip both plug connections (1) and disconnect.
Note:
Plastic holder with both cables of monitor sensors is removed with
catalytic converter.
RA Removing and installing intermediate pipe with catalytic converter
BMW AG - TIS
16.02.2013 14:55
Issue status (12/2007) Valid only until next DVD is issued
