23 00 035

Installing exchange transmission (S6S 420G)

Drain off gear oil from old transmission.

Catch and dispose of emerging gear oil.

Recycling:

Observe country-specific waste-disposal regulations.

Caution!

After 2000 km it is absolutely essential to carry out a
breaking-in inspection including an oil change,

refer to BMW Service Operating Fluids MG23.

Transmission must be filled with Lifetime oil.

Remove transmission.

Convert following components of old transmission to new
transmission:

Release bearing and release lever

Dowel pin for slave cylinder

Reversing light switch

Tightening torque, 23 41 5AZ.

Retainers for oxygen sensor cable

Transmission breather cap (in acc. with sticker on

transmission)

RA  Installing exchange transmission (S6S 420G)

BMW AG - TIS

16.02.2013  15:22

Issue status (12/2007) Valid only until next DVD is issued
