3 Series E46 M3 (S54) COUPE
33 17 002
Replacing rubber mount for rear differential
mounting at front (M3, M3 CSL)
Special tools required:
•
33 3 181
•
33 3 312
•
33 3 314
•
33 3 315
•
33 3 316
•
33 4 174
Necessary preliminary tasks:
•
Remove rear differential
If necessary, remachine special tool 33 3 181 .
Withdrawing rubber mount:
Withdraw rubber mount with special tools 33 3 312 , 33 3 314
, 33 3 315 , 33 3 181 and nut (1).
Note:
The remachined end of special tool 33 3 181 must point to the
rear axle carrier.
RA Replacing rubber mount for rear differential mounting at front (M3, M3 CSL)
