3 Series E46 M3 (S54) COUPE
Weld connection points for side window (1) and side frame (2).
Drill out connection points for inner side frame (with outer wheel
arch section) at
inner wheel arch section.
Weld rear panel
rear parcel shelf.
Weld connection point for rear parcel shelf and retaining bracket
for seatbelt fixture.
1 = Sunroof water drainage pipe
Grind down all connection points.
Make C-pillar reinforcement spare part.
If necessary, drill out sunroof water drainage pipe.
RA Replacing rear left or right outer wheel arch section (side panel removed) (E46
