3 Series E46 M3 (S54) COUPE
Park Distance Control (PDC) option:
Pull bumper (1) slightly towards rear and unclip cable holder in
area (2).
Disconnect plug connections on PDC sensors (3).
Remove bumper (1) towards rear.
Convertible with TV option only:
Disconnect plug connection (1) of TV antenna under center
console on left.
Feed out cable plug with grommet through rear panel.
Remove bumper towards rear.
RA Removing and installing complete rear bumper (M3, M3 CSL / lightweight design)
