3 Series E46 M3 (S54) COUPE
52 16 070
Removing and installing/replacing seat angle
adjuster on left or right front seat
(sport/electric)
Necessary preliminary tasks:
•
Remove front seat
•
Remove outer cover
Release screws (1).
Release screw (2).
Unclip carrier (3) from seat mechanism at rear.
Unlock plug connection (1) on drive unit (2) and disconnect.
RA Removing and installing/replacing seat angle adjuster on left or right front sea
