3 Series E46 M3 (S54) COUPE
61 31 492
Replacing level switch for windshield washer
system (M3, M3 CSL)
Necessary preliminary tasks:
•
Remove cover on right
Note:
Drain fluid reservoir for windshield washer system (3).
Unfasten plug connection (1) and disconnect.
Turn level switch for windshield washer system (2) in direction of
arrow and remove towards bottom from water reservoir for
windshield washer system (3).
RA Replacing level switch for windshield washer system (M3, M3 CSL)
BMW AG - TIS
16.02.2013 23:27
Issue status (12/2007) Valid only until next DVD is issued
