3 Series E46 M3 (S54) COUPE
11 24 Connecting Rods and Bearings S54
∅
Large connecting rod eye (without bearing)
mm
53.000
+0.013
Conrod bush bore diameter
∅
mm
21
+0.017
+0.013
Permissible total deviation of
connecting rods in one engine
(without bearing shells)
g
±
4
