3 Series E46 M3 (S54) COUPE
VS-14/Caris
Register/Index: 1
1 09 06 (261)
Vertrieb D
KDL d. VGs u.
Imp. z. Info
Datum/Date:
04/2006
Checking the wheel control joints on the front axle
E46 M3
Situation:
A contour plate with an adhesive pads for measuring device 31 1 060 has been
developed for the purpose of checking the wheel control joints with aluminium end cover.
See Enclosure 1.
The end cover on the wheel control joint is made of aluminium. This means adaptation of
the existing measuring head 31 1 063 with magnet is not possible. A steel contour plate
has therefore been developed that is adhered to the end cover of the wheel control joint,
thus allowing use of the measuring head 31 1 063 of measuring device 31 1 060.
Procedure:
Store tools are supplied to order.
Orders can be placed with the company Cartool, e-mail address: [email protected]
SWS Checking the wheel control joints on the front axle E46 M3
