3 Series E90 318d (M47T2) SAL
11 65 020
Removing and installing or replacing exhaust
turbocharger (M47T2)
Warning!
Scalding hazard!
Only perform these tasks on an engine that has cooled down.
Important!
Fit charge air hoses dry and without grease otherwise this
may result in supercharger malfunction.
Necessary preliminary tasks:
•
Remove air filter element
•
Remove intake manifold
•
Remove primary catalytic converter
Loosen bolts.
Turn holder (1) in direction of arrow.
Detach pressure hose (2) in direction of arrow.
RA Removing and installing or replacing exhaust turbocharger (M47T2)
BMW AG - TIS
19.01.2013 17:01
Issue status (12/2007) Valid only until next DVD is issued
