3 Series E90 320d (M47T2) SAL
Unlock plug (1) and remove.
Grip at hexagon head (2) when removing pressure sensor.
Release hexagon screw connection (3) on pressure accumulator.
Installation:
Secure position of pressure regulator and grip at hexagon
fitting (2).
Tighten down hexagon screw connection (3).
Tightening torque 13 53 13AZ
.
Note:
Check stored fault messages.
Now clear the fault memory.
RA Replacing pressure regulator on pressure accumulator of injection system (M47TU,
