3 Series E90 320d (M47T2) SAL
Release ear clamp (1).
Detach gaiter (2) from tie rod (3).
Installation:
Read and follow notes/information on spindle and rack sides at
the start of the document.
Clean tie rod and apply grease to taper. This ensures that the
gaiter is not rotated when the tie rod is rotated.
Release water drain valve (1) (20 A/F) and replace.
Installation:
Fit O-ring (2).
Tightening torque 32 00 3AZ
.
After installation:
•
Perform chassis alignment check
•
Carry out steering angle sensor adjustment
RA Replacing gaiter for electric steering gear (EPS) on left or right
