3 Series E90 320d (M47T2) SAL
64 52 521
Replacing A/C compressor (M47T2)
Warning!
Risk of injury!
Refrigerant circuit is under high pressure!
Follow safety instructions for handling R 134a refrigerant .
Avoid contact with refrigerant and refrigerant oil.
Follow safety instructions for handling refrigerant oil.
Important!
Risk of damage!
Restart engine only when A/C system has been correctly
filled.
Read and comply with notes on replacing compressor.
Follow instructions for opening and replacing parts in
refrigerant circuit!
If A/C system is opened for more than 24 hours:
Replacing drier insert for A/C system
Necessary preliminary tasks:
•
Drawing off, evacuating and filling the A/C system are not
included in the time value given for this work operation
•
Remove suction filter housing
•
Remove A/C compressor drive belt
•
Remove lower radiator cover
Release screws (1) and disconnect suction and pressure lines.
Installation:
Tightening torque 64 52 1AZ
.
Replace all sealing rings and moisten with refrigerant oil.
RA Replacing A/C compressor (M47T2)
