3 Series E90 320i (N46) SAL
Insert special tool 24 4 160 into opening of transmission housing
and clamp gently with screw (1).
Twist in screw (2) and clamp down.
Then tighten down screw (1).
Release bolts and remove transmission.
Tightening torque 24 00 1AZ
.
Installation:
Bore (1) in driving disk must be accessible from opening on
engine oil pan.
Check that adapter sleeves (2...3) are correctly seated.
Replace damaged dowel sleeves.
Installation:
Rotate torque converter until bore in torque converter is flush with
bore in driving disk.
Flange automatic transmission to engine.
RA Removing and installing automatic transmission (6HP19Z) N46
BMW AG - TIS
26.01.2013 05:02
Issue status (12/2007) Valid only until next DVD is issued
Copyright
Page - 5 -
