3 Series E90 328i (N51) SAL
11 72 Air pump, lines and control valves
Type
Thread
Tightening specification
Measure
1AZ Secondary air valve to cylinder head
N51
M6
8 Nm
2AZ Secondary air pump to engine
longitudinal member
N51
BM6
5 Nm
3AZ Intake hose / intake line to bracket
N51
M6
8 Nm
AZD Air pump, lines and control valves
