3 Series E90 335xi (N54) SAL
61 31 043
Removing and installing or replacing roof
switch centre
Special tools required:
•
00 9 341
Important!
Follow instructions for handling light bulbs (interior lights).
Important!
Read and comply with notes on protection against
electrostatic damage (ESD protection).
Important!
Reflector on ceiling light must not be damaged.
Carefully unclip trim of ceiling light (1) with special tool
00 9 341 in direction of arrow from ceiling light and remove.
RA Removing and installing or replacing roof switch centre
