3 Series E90 M3 (S65) SAL
Drive in both nozzles with special tool 11 9 360 on left and right
into crankcase.
Installation:
Always replace nozzles (1).
Moisten outlet holes (1) with actuator (2).
Install radial shaft seal at front.
Install radial shaft seal at rear.
Installation:
Prepare sealing compound (1) in special tool 11 4 370 .
Screw on nozzle for injecting sealing compound.
Press sealing compound nozzle in direction of arrow onto nozzle
at 90
°
.
Slowly and evenly insert sealing compound (1) with special tool
11 4 370 in direction of arrow.
Assemble engine.
RA Replacing crankshaft (S65)
